Friction materials seriesFibres for friction materials · brake pads / brake shoes / clutch facingsSpecification basis: per the batch test report
BE-F01 Mineral Fibre
BE-F01 is an asbestos-free man-made mineral fibre model in the BOER BE series for friction materials. Typical melting point ＞1000℃, fibre length/diameter ratio ≥35, shot content ＜2%; asbestos-free and RoHS/SVHC compliant, suitable for brake pads / brake shoes / clutch facings.
Product Overview
What is BE-F01
BE-F01 is an asbestos-free man-made mineral fibre model in the BOER BE series for friction materials. Typical melting point ＞1000℃, fibre length/diameter ratio ≥35, shot content ＜2%; asbestos-free and RoHS/SVHC compliant, suitable for brake pads / brake shoes / clutch facings.
Key features
- Wet-process manufacture: uniform surface treatment and stable quality
- Low shot content and good dispersibility in formulations
- High-temperature performance: melting point is ＞1000℃
- Surface treatment improves bonding with phenolic resin and other binders
- Asbestos-free; passed SGS asbestos, RoHS and SVHC testing
Packaging & storage
Normally packed in moisture-proof laminated bags or eco-friendly paper bags, with custom packaging on request. Store in a dry, ventilated place away from moisture, open flame and strong oxidizers.
Physical Properties
Typical parameters
| Appearance / Colour | Melting Point | Fibre Length/Diameter (L/D) | Shot Content (>125 μm) | Hardness | Density (g/cm³) | Moisture | Surface Treatment Content |
|---|---|---|---|---|---|---|---|
| 绿/灰 | ＞1000℃ | ≥35 | ＜2% | 6 | 2.82 | ＜2% | ＜6% |
Note: values above are model typical ranges; each shipment is governed by its batch test report.
Chemical Composition
Composition / raw-material information
| Substance | CAS No. | EC No. | Range |
|---|---|---|---|
| SiO₂ | 7631-86-9 | 231-545-4 | 56-72 |
| Al₂O₃ | 1344-28-1 | 215-138-6 | 13-30 |
| CaO | 1305-78-8 | 215-138-9 | |
| MgO | 1309-48-4 | 215-171-9 | ≤6 |
| K₂O | 12136-45-7 | 235-227-6 | |
| Na₂O | 1313-59-3 | 215-208-9 | |
| TiO₂ | 13463-67-7 | 236-675-5 | |
| Fe₂O₃ | 1309-37-1 | 215-168-2 | 4-8 |
| 纤维烧失率 | <1 | ||
| ROHS指令 | 符合 | ||
| 高关注物质测试 | 通过 |
Note: composition shows model typical ranges; subject to the batch test report.
Certification & Compliance
Testing & certification
- Asbestos-free: SGS test report CANEC25025290506 (2025-10-22); all 6 asbestos types, including chrysotile, not detected (XRD/PLM, detection limit 0.1%)
- RoHS: 10-substance test passed, report CANEC25025290502
- SVHC: 250-substance test passed, report CANEC25025290504, complying with applicable REACH requirements
- Quality system: ISO9001:2015 certified, registration 0350325Q30014R2S
- MSDS/SDS: prepared in accordance with REACH Annex II (e.g. EECSSDS2605060802)
See Certifications for certificate and report numbers; originals can be requested for verification.
FAQ
10 things you may want to know about BE-F01
Q1What products or processes is BE-F01 used for?
BE-F01 is an asbestos-free man-made mineral fibre model in the BOER BE series for friction materials. It is manufactured with the wet process and surface treatment, and is suitable for reinforcement formulations for friction products such as brake pads, brake shoes and clutch facings.
Q2How does BE-F01 differ from other models in the same series?
Registered models in the same series include BE-B03, BE-GL3, BE-SL05, BE-S06, BE-G3, BE-B07. BE-F01 is differentiated mainly by melting point, fibre length/diameter ratio and shot content; selection should be confirmed with product documentation and the batch test report.
Q3What is the melting point and heat resistance of BE-F01?
The melting point of BE-F01 is is ＞1000℃, suitable for high-temperature braking, sealing and coating applications. Specific values are subject to the batch test report.
Q4What is the shot content and dispersibility of BE-F01?
The shot content (non-fibrous material, >125 μm) of BE-F01 is approximately ＜2%; the wet process gives a more uniform surface treatment and better dispersion, with stable bonding to resins. Subject to the batch test report.
Q5Surface treatment and resin bonding of BE-F01?
BE-F01 is surface-treated by immersion, which improves the fibre specific surface area and surface activity; it bonds well with phenolic resin and disperses readily in formulations.
Q6Does BE-F01 contain asbestos?
No. BE-F01 is an asbestos-free man-made mineral fibre. It has passed SGS asbestos testing (report CANEC25025290506, 2025-10-22); all 6 asbestos types, including chrysotile, were not detected (XRD/PLM, detection limit 0.1%).
Q7Is BE-F01 RoHS/SVHC compliant?
Yes. Boer products have passed RoHS 10-substance testing (CANEC25025290502) and SVHC 250-substance testing (CANEC25025290504), complying with applicable REACH requirements.
Q8Is an MSDS/SDS available for BE-F01?
Yes. Boer can provide MSDS/SDS prepared in accordance with REACH Annex II (e.g. EECSSDS2605060802), and the batch test report is delivered with each shipment.
Q9How is BE-F01 packaged and stored?
BE-F01 is normally packed in moisture-proof laminated bags or eco-friendly paper bags, with custom packaging on request. Store in a dry, ventilated place away from moisture, open flame and strong oxidizers.
Q10How can I request a BE-F01 sample or selection support?
Call the national sales hotline 4006-0763-82 or email info@boerfibre.com. Boer provides selection advice, samples and batch test reports; commercial terms are subject to written confirmation.
